Lens Shift Range for Desktop and Ceiling Mount
Application
The diagram below shows the location of the image
position in the lens. The lens can be shifted within
the shaded area as shown using the normal
projection position as a starting point.
Maximum Possible Range for NP40ZL, NP41ZL,
NP43ZL:
Towards ceiling/floor: 0.5H
Away from ceiling/floor: 0.1H
Right: 0.3W
Left: 0.3W
(W: width of projected image, H: height of projected
image)
Note: Horizontal lens shift range is 0.15W at a
200” projected image with NP41ZL
