NEC Storage M110 - Part Name and Appearance Check

Part Name – Checking Appearance and Features
Check the mount positions for the components and LED.
Disk Array Unit
[Front view]
[3.5-inch disk drive-mounting model]
[2.5-inch disk drive-mounting model]
(4)Disk drive/Dummy carrier
(3)POWER LED
(1) ID LED
(2)SERVICE LED
３
(4)Disk drive/Dummy carrier
(3)POWER LED
(1) ID LED
(2)SERVICE LED
1-2-1 Disk Array Controller
