[Front view]
[Rear view]
Disk Enclosure
[Optional]
(1)Adapter (ADP1)
(1) Adapter (ADP0)
(2) Power supply (PS1) (2) Power supply (PS0)
Same as the Disk Array Unit.
See the “Front view” of the Disk Array Unit.
1-2-2 Disk Enclosure (optional)
[AC power mounting model] [DC power mounting model]
(1)Adapter (ADP1)
(1) Adapter (ADP0)
(2) Power supply (PS1) (2) Power supply (PS0)
