Necchi FA16 - Needle Threader; Drawing up the Bobbin Thread

12
1
1
3
2
2
1
Drawing up the Bobbin Thread
z Raise the presser foot and hold the needle thread
lightly with your left hand.
q Needle thread
x Turn the handwheel slowly toward you one complete
turn. Bring the bobbin thread up by pulling the needle
thread as illustrated.
c Pull 4˝ (10 cm) of both threads back and under
the presser foot.
q Needle thread
w Bobbin thread
Needle Threader
z Raise the needle to its highest position.
Pull down the needle threader knob as far as it will go.
x Turn the knob in the direction of the arrow in the
illustration, then insert hook into the needle eye.
Lead the thread around guide and under hook.
c Turn the knob in the direction of the arrow in the
illustration, drawing the thread loop through the
needle.
Pull the thread through the needle eye.
* The needle threader can be used with a #11 to #16
needle or a Janome Blue tipped needle. Thread size 50
to90shouldalsoworkwell.
x
z
c
x
z
c
w
q
q
