NECTA SPA TECHNICAL MANUAL “SFERA “

Manual “ SFERA” 10 / 19

POWER SUPPLY AND LIGHTING DIAGRAM

2 1

3 4

Wiring diagram of dispensing

compartment slider lock device kit

1 – 2 Power supply - EXE

3 – 4 Connector J14 - 24 V DC

CPU board power supply

5-6-7-8 Connector J3

IN / OUT to CPU

J 3

J 2

J 1
