ADAPTOR (AV BOX)
3
BRIGHTNESS
TINT
SCREEN MODE
COLOR
4
IR HEADPHONE
(OPTIONAL)
IN 2
A (L) A (R)V
AV BOX
IN 1
A (L) A (R)V
OUT
A (L)A (R) V
RED-ACC
YELLOW-BATTERY
BLACK-GND
13 PIN
TO MONITOR
ADAPTORS
INPUT DC-13.2V
FUSE 2A
SERIAL NO.
MADE IN TAIWAN
AV Out put To Moni t orAV2 I nputAV1 I nput
TOP
MODE : ON / OFF and
Mode Selection
Infra-Red Remote
Controller Receiver
DOWN : Positive and Negative Adjustment
MENU : Activation of Menu Indicator
UP : Positive and Negative Adjustment
SCREEN MODE
BRIGHTNESS Adjustment
TINT Adjustment
On Screen Display (OSD) Indicator
Color Adjustment
Basic Operation (Monitor)
Interconnect Cable
Assembly , Monitor
Electrical Connections (General)
Red Wire : ACC
Black Wire : Ground
Yellow Wire : Battery (+)
Wiring System :
