Cube card reader 190
SPECIFICATIONS
Cube card reader 190
:
Product number: 9205543 CUBE card reader M190
9205527 CUBE card reader MK190
Dimensions: 7.52 x 2 x 1.2 in
Protection: IP65 Weight: ± 0.78 lb
Power Supply: 12VDC – 30VDC Power consumption:
M190: 60mA@12VDC, 35mA@24VDC
MK190: 90mA@12VDC, 45mA@24VDC
Environment: Temperature: Operating and Storage: -31°F to +150°F
Relative humidity: 10 – 93% non condensing
Communication: RS485 (Encrypted AEOS protocol to AP4x03, (firmware APx003rs485NR).
Indicators: UL (green) NA (red) ,MD (blue)
Antennas (internal): 13.56 MHz, Mifare compatible Detection distance Mifare card: 1.5 in
R&TTE: Hereby, Nedap N.V., declares that these products comply with the essential requirements and provisions of the
Directive 1999/5/EC of the European Parliament and of the council of March 9, 1999 on Radio equipment and
Telecommunications Terminal Equipment and the mutual recognition of their conformity and with the provisions of
Annex IV (Conformity Assessment procedure referred to in article 10).
CABLE SPECIFICATIONS
10 wire shielded cable of approx. 10 ft length included (pig tail). Extensions can be made:
RS485: 22AWG twisted pairs, shielded, max cable length: 3280 ft, cable capacity <= 33pF/ft.
Power: 22AWG twisted pairs, shielded, max cable length: 160 ft.
MORE INFORMATION: For more detailed information contact your local Nedap supplier or check the internet site.
FCC and IC CERTIFICATIONS
This device complies with part 15 of the FCC Rules and to RSS210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
Cet appareil se conforme aux normes RSS 210 exemptés de license du Industry Canada.
L'opération est soumis aux deux conditions suivantes:
(1) cet appareil ne doit causer aucune interférence, et
(2) cet appareil doit accepter n'importe quelle interférence, y inclus interférence qui peut causer
une opération non pas voulu de cet appareil.
Les changements ou modifications n’ayant pas été expressément approuvés par la partie responsable de
la conformité peuvent faire perdre à l’utilisateur l’autorisation de faire fonctionner le matériel.
