Cube card reader 190
LED INDICATORS FRONT
At the front a three colour LED is positioned at the middle of the Cube card reader 190
Depending of the used configuration the function of these LEDs can differ:
• Green LED: Card is been authorised (UL led)
• Red LED: Card is not authorised (NA led), controller is stand-by
• Blue LED:
Blinks fast: No configuration is available at this Cube card reader
(load Configuration first).
Continuously ON: Determined by configuration: E.g. Reader stand-by.
(Blue LED is activated if UL is OFF and NA is more than 1 sec OFF)
Remark: Function of LEDs and Beeper is controlled by used application settings of Cube card reader.
FIRMWARE
Pay attention that the firmware loaded in the Cube card reader 190 together with the Cube card reader
190 type and configuration determines functionality and protocols.
Remark: The Cube card reader 190 requires dedicated firmware (not identical to the Cube card
reader MK170 firmware)
SYSTEM CONFIGURATIONS (how to connect Cube card reader 190)
To CUBE Core or CUBE Access Plus with RS485 special encrypted protocol.
(LED’s, Beeper and Keys are controlled over the RS485 communication)
