Nederman FilterCart Original Instruction Manual

FilterCart OriginalEN
12
144027(01)
4 Technical and electrical data
See Figure 1 and the following list for an overview of the unit’s physical
appearance and measurements:
1. Horisontal swiveling arm.
2. Start/stop Re-set overload protector.
3. Depending on arm:
• 2 m arm: max. 1650 mm (65").
• 3 m arm: max. 2050 mm (81").
Table 4-1: Technical data
Capacity 750–1050 m
3
/h (430–620 cfm)
Filtration eciency, main lter > 99 % average weight ltration eciency
Filtration eciency, HEPA lter > 99.97 % DOP 0.3 µm
Filter area, main lter 35 m
2
(377 ft
2
)
Filter area, HEPA lter 7.5 m
2
(81 ft
2
)
Motor power 0.75 kW (1 hp)
Voltage * 110/120/2390/240
Phase * 1 ~
Frequency * 50/60 Hz
Spot light 20 W, 24 V
Transformer 24 V secondary
Weight: • 71 kg (156 lb) with 2 m arm
• 73 kg (161 lb) with 3 m arm
Temperature, max. ambient temp. 40 °C (104 °F)
Temperature, max. airow temp. 60 °C (140 °F)
Noise level 73 dB(A) ISO 11203
Material recycling 90 weight-% without lter cartridge
* See type label.
See wiring diagram, Figure 2, for electrical details.
E1: 20 W, 24 V.
F1: Start/stop overload protector.
F2: 1 AT, 5 x 20 mm.
T1: Transformer.
M1: 0.75 kW.
Black: Black wire.
Brown: Brown wire.
Blue: Blue wire.
