Nedo ACCEPTOR 2 digital - Device Configuration; Front Panel Components; Back Panel Components

9EN Operating instructions
2 Equipment configuration
2.1 Front
1 Battery compartment
2 Fixing clip fixing M6 thread
3 Conical clip guide
4 LCD display for laser receiver
5 Sound signal - output
2.2 Back
1 Keypad
2 LCD display for laser receiver
3
Spirit level for aligning for
marking work
4 LED laser level indicator
5
Setpoint level middle marking
(40 mm from top of housing)
6 Laser reception field (50mm)
1
2
3
4
5
1
2
3
4
5
6
