NEEWER PL60C - Troubleshooting

EN
09
When purchasing DMX cables from a third party, please
check the interface protocol and make sure it is compati-
ble with the light.
Troubleshooting
Troubleshooting
High Input Voltage
High voltage protection
DMX interface protocol is shown below:
Low voltage protection
High temperature
protection
Low temperature
protection
Low Input Voltage
High Temperature
Low Temperature
Operating Instructions
5
4
3
2
1
Not assigned
Not assigned
Common
signal
Data（+）
Data（-）
1
2
3
4
5
Common signal
Not assigned
Data（-）
Data（+）
Not assigned
