en Installation
14
5Installation
Installation
Preparing for installation
Caution!
Ensure that there are no electrical wires, gas pipes or
water pipes in the area where holes are to be drilled.
1. Cover the hob to protect it from damage.
2. Mark where the centre of the extractor hood should
be on the ceiling above the centre of the hob.
3. Using the template provided, mark the locations
where the bolts should be inserted on the ceiling.
4. Drill four 8 mm diameter holes to a depth of 80 mm
for fastening the appliance and press in the wall
plugs flush with the wall.
Preparing the appliance
1. Screw in the four bolts on the edge of the frame at
the marked locations, leaving them protruding out of
the frame by approx. 5 mm.
2. Remove the film from the frame cover.
3. Remove the activated charcoal filter from the film.
4. Open the cover on the top of the appliance and
remove it ¨, insert the activated charcoal filter ©
and then close the cover.
NJONN
