Installation instructions en
23
4.
Press together the cable duct at the sides and re-
move it.
5.
Disconnect the cable at the appropriate point.
6.
Loosen the screws on the side covers.
7.
Remove the side covers.
8.
Undo the screws on the hinges up to approx.7mm.
Do not loosen them fully.
9.
Unhook and remove the filter cover.
10.
Undo the opposite screws to loosen the fan box.
11.
Push the fan box to the side and release the pipe-
work.
12.
Push the fan box to the other side and pull out the
mains plug.
13.
Screw the fan box firmly back in place.
14.
Loosen the mounting brackets. Push the removal
slide inwards.
15.
Slowly take the appliance out of the cutout.
16.
Insert the side covers into the corresponding open-
ings and screw them firmly in place.
