16. To check that the settings were saved successfully, click on the “Search Device” button again.
The changed network device IP address should appear in the dialog box above the “Search
Device” button. Click on this device and ensure that all parameters were changed correctly.
17. Remove the jumper as mentioned in step 2 for the NemLink boards. Install the jumper on the 2
lower pins for the 8-way Relay board.
18.
The network device is now ready for installation.
Programming IP Addresses
