Mercury Neo electric scooters Part Code: Z40948 (Rev A)
Owner’s Handbook Page 22 of 24
SPECIFICATION
Neo Neo 6 Neo 8
Dimensions (L x W x H) 126cm x 58cm x 112cm (49½” x 22¾” x 44”)
Total Weight 80kg (176lb) 86kg (190lb) 92.5kg (203.5lb)
Battery 2No. 12V 36ah (compliant with IATA special provision A67)
Motor 350W 24V DC 450W 24V DC 500W 24V DC
Control system CTE 70A CTE 70A Dynamics Rhino 110A
Drive system Direct drive to rear wheels (with transaxle)
Brake system Electromagnetic (EM) and regenerative EM and regenerative.
Secondary cable brake.
Turning radius 110cm / 43¼”
Front / rear tyre 4No. 3.0-4 grey pneumatic (25cm x 10cm / 10” x 4”)
Charger 4A 24V DC
Maximum speed 4mph / 6.4kph 6mph / 9.7kph 8mph / 12kph
Climbing angle 8° / 1 in 7
Cruising range 20 miles / 32 km
Maximum user weight 135kg / 21 stone
Note:
• Maximum driving distance (cruising range) is based on an ambient temperature of 20°C, a 100kg
driver and a battery which has reached optimum capacity, a constant driving speed of 4mph / 6kph
with 70% battery power discharged.
• When a battery is new off-the-shelf it is approximately two-thirds of its optimum capabilities.
During the first 3 – 6 months of use the batteries will improve to a peak point at which they will
remain for 50% - 60% of their expected lifespan (if maintained and charged correctly, as
described in this manual). At this point the batteries will begin to deteriorate until they will require
replacing. It is for this reason that the batteries must
be correctly charged at all times else the peak
point reached may not be the batteries’ optimum capacity and their lifespan may be dramatically
reduced.
• The manufacturer reserves the right to modify the specification if necessary. The final
specification is subject to the individual scooter your purchase from your dealer.
