neomouv KALYSO - Technical Data

KALYSO – KALYSO HY – KALYSO NV manual
24
8 - TECHNICAL DATA
FITTINGS MAX. TIGHTENING TORQUE (Nm)
Pedal axle 40
Pedals 20
Front wheel axle 25
Rear wheel axle 25
Seatpost 6
Stem and handlebar 10
Saddle angle 13
CHARACTERISTICS
MODEL KALYSO/KALYSO HY/ KALYSO NV
Distance between the wheels 1200 mm
Total weight (battery included) 22 kg
Maximum load allowed 120 kg
Maximum speed in assistance mode 25 km/h
Battery range 70 to 80 km (480 Wh)
80 to 100 km for (580 Wh)
100 to 110 km for (630 Wh)
110 to 130 km for (700 Wh)
(for a user weighing 75 kg and riding at an average speed of 18 km/h in Eco mode)
Battery Lithium Ion cells
750 cycles
Voltage 36 V
Motor: Neo Assist
Nominal yield 250 watts
Charger voltage 42 V
Tyre dimensions 26’ or 28’
Tyre pressure 3.5 bars
SHIMANO derailleur (indexed control)
Development 14, 16, 18, 20, 22, 24, 28
(number of teeth on the sprockets)
Transmission Nuvinci infinity 330
Chainring (number of teeth) 40
