Connecting to a computer for recording
Before getting started, please install the “ AUDACITY ” recording software to your computer. Below is an example using a
computer with Microsoft XP and the Audacity software installed. For more options, please refer to the Audacity software guide
separately.
1) Turn on your computer and allow it to boot up fully. Turn the unit power ON, connect the USB port from the unit to your
computer via the USB cable provided. The unit connected to your PC will be recognised as a USB device.
2) Open the “ AUDACITY ” program. Under the “ EDIT ” tab, select “ PREFERENCES ”.
3) Click the “DEVICE” tab and then choose the “USB Audio Controller” at Recording and Playback device section
4) Select Channels “2 (STEREO)” and then click “OK” to close preference setting window.
5) Play the music, eg. Radio/Aux/Phono to be recorded into the computer.
6) Click the red Record button on the software control panel. You will see a waveform moving and can listen to the record
playing through your computer’s speakers or headphone.
7) When you have finished the recording, click the yellow Stop button on the software control panel.
8) Now click “FILE ” and choose to save your recording file.
9) Click the green Play button to playback your finished recording.
NOTE:
Free software (AUDACITY) licensed under the GNU general public license (GPL).
More information as well as open source code can be found on the provided CD or on the website at:
http://audacity.sourceforge.net/
IMPORTANT NOTES
LISTENING AND EXPORTING TO MP3
To listen to your digitized audio, you will need a third party application that can play WAV files. You can also use any standard
audio CD burning software to burn your WAV files to an audio CD.
If you would like to save your vinyl recordings as MP3 files after recording them using AUDACITY, you will need to install the
optional "LAME MP3 ENCODER" plug-in to the software provided on the CD. Once a file is in MP3 format it can be played on
any MP3 compatible mobile digital device.
The provided CD also included the LAME MP3 Encoder plug-in.
In AUDACITY, when you attempt to EXPORT AS MP3… for the first time after installing the lame MP3 encoder plug-in,
you will be asked for the location of the plug-in file. Browse to the LAME MP3 PLUGIN FOLDER you copied the plug-in
file to and select the file. Subsequently, audacity will remember the location of this file.
Software Name Operation System
Lame_Library_v3.98.2_for_Audacity_on_OSX Audacity 1.2.5 on Mac OS X (Intel)
LameLib-Carbon-3.91 Audacity 1.2.6 on Mac OS X (PPC)
Lame_v3.98.2_for_Audacity_on_Windows
Audacity 1.2.6 on Windows
(Me/2000/XP/Visa)
Line out connection
You can connect the system to your whole hi-fi system by connecting the line out socket (41) to the auxiliary input socket with
an RCA cable (not included).
X-bass sound effect
Press the x-bass button (19) to active x-bass function and enhance the bass effect at “ on “ position.
Remote control transmitter
Battery installation (batteries not included)
The infra-red transmitter requires 2 pc AAA size batteries for operation
E-7
