8233D PRO-EN
7
Range
Resolution
Accuracy
200Ω
0.1Ω
±（0.8% rdg + 2dgt）
2kΩ
0.001kΩ
20kΩ
0.01kΩ
200kΩ
0.1kΩ
2MΩ
0.001MΩ
±（1.0% rdg + 2dgt）
20MΩ
0.01MΩ
4.2.4 Diode check
Range
Resolution
Function
0.001V
Will display the forward drop voltage.
* Operating current：about 1mA
* Open circuit voltage：about 1.48V
4.2.5 Continuity
Range
Function
If measured resistance less than 100Ω, will buzzer is
sounded.
* Open voltage: about 0.5V
4.2.6 DC Current
Range
Resolution
Accuracy
200µA
0.1μA
±（1.5% rdg + 3dgt）
2000µA
1µA
20mA
0.01mA
200mA
0.1mA
10A
0.01A
