2 Board Interfaces
The following table lists the interfaces of N20 demo board.
Interface
Function
5 V power supply
Main power supply input, 3.3 V to 4.2 V
5 V power supply switch
Pull it to DC5V side to supply power if a DC adapter is used; pull it to
USB5V side to supply power if the board is supplied power through
USB.
SIM
Normal SIM card connector
UART0
Used to commission AT commands
UART1
Not supported
Antenna
Main antenna and GPS antenna
PWRKEY button
After supplying power to the module, hold this button for 1 second to
power up the module
RESET button
Hardware reset
USB
Used to supply power and transmit data & firmware upgrade
USB_BOOT
Force the module to enter download mode
