4. EQUIPMENT CHARACTERISTRICS
The table below shows capacities vs. channel bandwidth and modulation type. Capacity is shown in terms
of E1s/T1s, but may be mixed with Ethernet traffic to a combined capacity as shown in the table.
Bandwidth and Modulation
Transmission
capacity
4 State
16 State 32 State 64 State 128 State
4 x E1 7 MHz
8 x E1 14 MHz 7 MHz
16 x E1 28 MHz 14 MHz
20 x E1 14 MHz
40 x E1* 28 MHz
50 x E1* 28 MHz
75 x E1* 55/56 MHz 40 MHz 28 MHz
4 x T1 5 MHz
8 x T1 10 MHz 5 MHz
16 x T1 20/25 MHz 10 MHz
32 x T1* 20/25 MHz 10 MHz
64 x T1* 40/50/55 MHz 30 MHz 20/25 MHz
* Capacities from 40xE1 or 32xT1 and up require SW-license.
4.1. Frequency bands
The Evolution Series XPAND is available in ITU-R, CEPT, FCC and national frequency bands
according to the following tables. The BW given in the last column is for information only and indicates
which BWs the plan includes. Details about ODU tuning range is found in Appendix 1.
Frequency
Band
Frequency
[GHz]
Channel Plan
Duplex
spacing
[MHz]
BW [MHz]
L6 GHz 5.9-6.4
ITU-R F. 383-7
CEPT 14-01E
252.04 29.65
U6 GHz 6.4-7.1
ITU-R F.384-8
CEPT 14-02 E
340 20/30/40
7 GHz 7.1-7.4 ITU-R F.385-7 Annex 3
196
28
7 GHz 7.1-7.4 CEPT 02-06 Annex 1
154
7/14/28
7 GHz 7.1-7.4 ITU-R F.385-8 Rec. 1-4
161
7/14/28
7 GHz 7.1-7.4 ACA Rali FX3
270
30
7 GHz 7.2-7.5 ITU-R F.385-8 Rec. 1-4
161
7/14/28
7 GHz 7.4-7.7 ITU-R F.385-8 Annex 3
168
28
7 GHz 7.4-7.7 ITU-R F.385-8 Annex 1,4
154
28
7 GHz 7.4-7.7
ITU-R F.385-8 Annex 1, 1
CEPT 02-06 Annex 1
154 7/14/28
7 GHz 7.4-7.7 ITU-R F.385-8 Rec 1-4 161
7/14/28
7 GHz 7.4-7.9 ITU-R F.385-8 Annex 4 245
7/14/28
7 GHz 7.1-7.7 “Korea”
300
30
