NGP\00329 Rev. C 23-06-2006 Evolution Series - XPAND 29
5.2.4. Receiver Threshold 16xE1 - 14 MHz BW
Frequency band:
[GHz]
L6 U6 7 8 11 13/15 18 23 26 32 38
BER ≤ 10-6 [dBm]
-81.5 -81.5 -81.5 -81.5 -81 -80.5 -79.5 -79.5 -79 -77.5 -77
BER ≤ 10-8 [dBm]
-80.5 -80 -80 -80 -79.5 -79 -78 -78 -77.5 76.5 -76
BER ≤ 10-10 [dBm]
-79 -78.5 -78.5 -78.5 -78 -77.5 76.5 76.5 -76 -75 -74.5
Table 5-5 Receiver threshold 16xE1 in 14 MHz channel
5.2.5. Receiver Threshold 16xE1 - 28 MHz BW
Frequency band:
[GHz]
L6 U6 7 8 11 13/15 18 23 26 32 38
BER ≤ 10-6 [dBm]
-85 -85 -85 -85 -84.5 -84 -83 -83 -82.5 -81 -80.5
BER ≤ 10-8 [dBm]
-84 -83.5 -83.5 -83.5 -83 -82.5 -81.5 -81.5 -81 -80 -79
BER ≤ 10-10 [dBm]
-82.5 -82.5 -82.5 -82.5 -82 -81.5 -80.5 -80.5 -80 -79 -78
Table 5-6 Receiver threshold 16xE1 in 28 MHz channel
5.2.6. Receiver Threshold 20xE1 - 14 MHz BW
Frequency band:
[GHz]
L6 U6 7 8 11 13/15 18 23 26 32 38
BER ≤ 10-6 [dBm]
-80.5 -80.5 -80.5 -80.5 -80 -79.5 -78.5 -78.5 -78 -77 -76
BER ≤ 10-8 [dBm]
-79.5 -79.5 -79.5 -79.5 -79 -78.5 -77.5 -77.5 -77 -75.5 -75
BER ≤ 10-10 [dBm]
-78.5 -78 -78 -78 -77.5 -77 -76.5 -76.5 -75.5 -74.5 -74
Table 5-7 Receiver threshold 20xE1 in 14 MHz channel
5.2.7. Receiver Threshold 40xE1 - 28 MHz BW
Frequency band:
[GHz]
L6 U6 7 8 11 13/15 18 23 26 32 38
BER ≤ 10-6 [dBm]
-78.5 -78 -78 -78 -77.5 -77 -76.5 -76.5 -75.5 -74.5 -74
BER ≤ 10-8 [dBm]
-76.5 -76.5 -76.5 -76.5 -76 -75.5 -74.5 -74.5 -74 -73 -72
BER ≤ 10-10 [dBm]
-75 -75 -75 -75 -74.5 -74 -73 -73 -72.5 -71 -70.5
Table 5-8 Receiver threshold 40xE1 in 28 MHz channel
