Overview of the parts
1 Key for water tank and fridge doors
2 Cup plate
3 Telemetry device*
(located inside the machine)
4 Capsule insertion slot
5 Machine fridge
6 Proximity sensor*
7 Touch control panel
8 Coee and milk outlets
9 Capsule container
10 Milk tank lid**
11 Milk tank**
12 Milk aspiration pipe
13 Water tank lid
14 Water tank**
15 Main switch (the drip tray must
be removed in order to access the
main switch.)
16 Cup support
17 Drip grids**
18 Drip tray inlets
19 Drip tray
20 Drip tray assembly
21 Cleaning tank with lid (used
during the cleaning process)**
22 Location for the cleaning tablet
during the cleaning process
23 Water filter
24 Water hardness test strip
25 Jar of Thermoplan cleaning tablets
(used during the cleaning process)
26 Waste water container
(used during the cleaning process)
Test strips are available within the
water filter package.
i
2.3. Momento Coee & Milk
11
10
21
22
14
13
23
25 26
24
* Function not available in all countries. Please contact your Nespresso representative for more details.
** Machine part is dishwasher safe.
