ServiceManualC91/D91 enVersion1.0
Repair
Safetyinstructions
Riskoffatalelectricalshock!
Mainsvoltageinsidethecoffee
machine.
Disconnectthemainsplugbefore
disassemblythecoffeemachine
mustbefreeofvoltage.
Dangerofburns!
Hotpartsandwaterunderpressure
insidethecoffeemachine(ther
moblockinparticular).
Letcoffeemachinecooldownbefore
disassembly.
Generaldisassembly
Tool:
 Torxscrewdriverforsecurityscrews,
Pin TX10
IllustrationofaPinTXscrewhead
Emptywatersystemifnecessary
(seepage12).
Procedure:
1. Removewatertank(15)anddriptray( 5)
togetherwithdripgrid(4)andcapsule
container(6).
2. Remove2screws(20)onthefrontsideof
themachine.
3. Placemachineontherepairing/service
holderdevice(seepage42) .
4. Remove6screws(20)onthebottomof
themachine.
5. Swingoutandremovebothsidepanels(1).
6. Removelowerchassis(2).
