Ness L300 - Orthosis Electronic Module Handling

NESS L300 User Guide 35
Removing and Installing the Orthosis
Electronic Module
The following figure shows how to detach the electronic module from the
orthosis, this should be done only for cleaning the orthosis, or for
maintenance purposes.
1. Pull the upper edge of the electronic module out of the cradle.
2. Pull the electronic module out of the cradle.
3. To reinstall the module, insert the bottom part into the cradle and
push the module gently into the cradle to reinstall.
Figure 15: Removing the electronic module from the orthosis
Note
No more than one control and stimulation unit can be
registered in your system at any time, registering a
new unit will automatically remove your old unit from
the system.
