The NVDIMM LEDs blinks while destaging contents when you halt the system. After the destage
is complete, the LED turns off.
1. If you are removing or moving an NVDIMM, unlock the locking latch on the riser, and then remove the
applicable riser.
Air duct cover
Riser 2 and NVDIMM 11
2. Note the orientation of the NVDIMM in the socket so that you can insert the NVDIMM in the replacement
controller module in the proper orientation.
3. Eject the NVDIMM from its slot by slowly pushing apart the two NVDIMM ejector tabs on either side of the
NVDIMM, and then slide the NVDIMM out of the socket and set it aside.
1013
