Step Perform on each controller module
Cable the cluster/HA ports to each other with the 100 GbE (QSFP28)
cable:
• e0a to e0a
•
e0d to e0d
If you are using your onboard ports for a data network connection,
connect the 100GbE or 40Gbe cables to the appropriate data network
switches:
•
e0g and e0h
