NetComm NF18ACV Guide

NF18ACV NC2 FAQs – Change Administration Password Guide
2 of 3
FQ01101 v. 1.0 March 2019
© NetComm Wireless 2019
Change the default password
This guide will take you through the process of changing the password required to login to the Administration
page of your NF18ACV.
Initial log in to the Web interface of the NF18ACV
1 Open a web browser (such as Google Chrome or Mozilla Firefox), type following address into the address
bar and press
Enter.
http://192.168.20.1
2 Enter the following credentials in the
User Name and Password fields:
User Name:
admin
Password:
admin
3 Click the
Login > button.
Note
– If no authentication prompt is displayed or you see a request time out message, refer to the What if I cannot access Web User
Interface guide from FAQs section.

NetComm NF18ACV Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1600 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11d, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB port	-
RJ-11 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Product type	Tabletop router
Product color	White
Output current	2 A
Output voltage	12 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	28 mm
Width	216 mm
Height	174 mm
Weight	558 g
