NetCommWireless NTC-400 Series Quick Start Guide

| Wireless M2M
5
NTC-400 Series Router
I/O specications
MODE SPECIFICATIONS
Digital Input
(DI-1 and DI-2)
Trigger voltage (high) Logic level 1: 5 V to 30 V
Normal voltage (low) Logic level 0: 0 V to 1.0 V
Digital Output
(DO)
Voltage (Relay mode)
Logic level 1: Depends on external device.
Maximum voltage is 36 V.
Logic level 0: Floating, External pull-down
resister (10 k Ω, 0.5 W) is required.
Note: DO power is relayed from the PWR
pin on the 8-pin terminal block connector.
Maximum current 1 Amp @ 12 V, or 0.33 Amp @ 36 V
Power requirements
The NTC-400 Series router accepts DC power in the range of 9 V to 36 V. Follow
the above illustration to ensure that the power source is connected with the
correct polarity.
