Security Gateway Manual SG-1100
2.4 Installing the Wallmount Kit
This page shows how to install the optional SG-1100 Wall Mount Kit.
Tip: Save the SG-1100 MAC Address, Serial Number, and NDI, located on the bottom of the system, before attaching
the SG-1100 to the wall.
Fig. 3: Loop one side of the Silcone Band under the wall mount of the SG-1100
Note: Remove the rubber standoff feet from the SG-1100 prior to attaching to the wall mount. Do not remove the
screws that are under the rubber standoff feet.
Tip: Remember to save the SG-1100 MAC Address, Serial Number, and NDI, located on the bottom of the system,
before attaching the SG-1100 to the wall.
Hang the wall mount with the cables hanging down. Secure the cables to the holes on the wall mount with cable ties
to relieve the weight from the ports.
© Copyright 2020 Rubicon Communications LLC 37
