Security Gateway Manual SG-3100
Category Description
CPU
ARM v7 Cortex-A9 @ 1.6 GHz with NEON SIMD
and FPU
CPU Cores
Dual Core
Networking
Two 1 Gigabit Ethernet Ports,
configured as dual WAN or one WAN one LAN
plus four-port 1 Gbps Marvell 88E6141 switch,
uplinked at 2.5 Gbps to the third port on the SoC
for LAN.
Storage
8 GB eMMC Flash onboard,
upgradable to 32 GB M.2 SATA SSD
Memory
2 GB DDR4L
Expansion
2x M.2 ‘B’ key sockets (SSD, LTE)
1x M.2 ‘E’ key socket (2230 form factor) for WiFi /
Bluetooth
1x miniPCIe (WiFi)
microSIM
Console Port
MiniUSB (console cable included)
USB Ports
1x 3.0 port
LED
3 user-controllable full-color RGB LEDs
Enclosure
Desktop 1.56” tall x 7” deep x 8” wide
Form Factor
Standard mini-ITX 170mm x 170mm
Cooling
Passive (no fan)
Power
External ITE P/S AC/DC 100-240V, 50-60 Hz, 12V
3.33A,
threaded barrel connector
AC Inlet: IEC320-C14 (3 PIN)
One US, UK, EU or ANZ power cord included
US Power Cord: NEMA 5-15P to IEC320-C13
UK Power Cord: BS 1363 to IEC320-C13
EU Power Cord: CEE7/16 to IEC320-C13
ANZ Power Cord: AS 3112 to IEC320-C13
Environmental
32°F (0°C) to 149°F (65°C)
Certifications
FCC, CE, RoHS, UL, IEC-60950
© Copyright 2022 Rubicon Communications LLC 16
