Hardware Setup
14
N750 Wireless Dual Band Gigabit ADSL Modem Router DGND4000
Note: You can use either the ADSL or Gigabit Ethernet port for WAN
connectivity.
5. AC power adapter input
6. Power On/O
ff button
Front Panel
The wireless modem router front panel has the 10 status LEDs, icons, and ports shown in the
figure. The Wireless On/Off and WPS icons are buttons.
Power
LAN ports
DSL
Internet
5 GHZ wireless
USB port
Wireless On/Off button
WPS On/Off button
2.4 GHz wireless
USB
Figure 4. Front panel LEDs
The following tables describe the LEDs, icons, and buttons on the front panel from top to
bottom.
