B-1connector pin assignments
APPENDIX B: CONNECTOR PIN ASSIGNMENTS
This appendix provides information about the RJ-45 plug and the RJ-45 connector used
for the NETGEAR FS726 and FS750 Switches.
RJ-45 Plug and RJ-45 Connector
In a Fast Ethernet network,it is important that all 100BASE-T certified Category 5
cabling use RJ-45 plugs.The RJ-45 plug accepts 4-pair UTP or shielded twisted-pair
(STP) 100 ohm cable and connects into the RJ-45 connector.The RJ-45 connector is
used to connect stations, hubs, and switches through UTP cable; it supports 10 Mbps,
100 Mbps, or 1000 Mbps data transmission.
Figure B-1 shows the RJ-45 plug and RJ-45 connector.
Figure B-1.RJ-45 Plug and RJ-45 Connector with Built-in LEDs
