NETGEAR N300 Configuration Guide

RingCentral certified router Netgear N300
6. Check the box next to “Turn Internet Access QoS On” if not
already checked.
7. Check the box next to “Turn Bandwidth Control On”.
8. Select the “Uplink bandwidth Maximum” radial button.
9. In the field to the right of the radial button enter in your current
upload speed. (If unsure of the current upload speed, run a
speedtest at http://www.ringcentral.com/support/capacity.html).
10. Be sure to save any changes and reboot the router
before proceeding.
11. Your QoS should now be configured.
6
7
9
8
10

NETGEAR N300 Specifications

General

WiFi Technology	802.11n
WiFi Speed	300 Mbps
Frequency Band	2.4 GHz
Security	WPA/WPA2
Antenna	2 external antennas
Ethernet Ports	4 x 10/100 Mbps
