NETGEAR N900 - Page 5

3
The router has two buttons and several LEDs on the front.
• WPS button. Use WPS to add a wireless computer or device to
the network.
• WiFi On/Off button. Turn the wireless radios on and off.
Table 1. LEDs
LED Description
WPS
• Solid green. Wireless security (such as, WEP, WPA-PSK,
or WPA2-PSK) is enabled on the router.
• Blinking green. The router is performing WPS activities.
This LED continuously blinks if the router is in the WPS
PIN auto lockdown state.
• Off. All wireless radios are disabled, and there is no WPS
activity.
Power
• Solid amber. The router is starting up.
• Solid green. The router is ready.
• Blinking green. The firmware is corrupted. Visit http://
support.netgear.com.
• Off. Power is not supplied to the router.
Internet
• Solid green. The Internet connection is ready.
• Solid amber. The Ethernet cable connection to the
modem was detected.
• Off. No Ethernet cable is connected to the modem.
2.4 GHz
and 5 GHz
• Solid green. The wireless radio is operating in either
2.4 GHz or 5 GHz mode.
• Blinking. The router is in WPS mode.
• Off. The wireless radios are off for both 2.4 GHz and
5 GHz.
LAN ports
1–4
• Solid green. The LAN port detected a 10/100 Mbps link
with an attached device.
• Solid amber. The LAN port detected a 10M/100Mbps link
with an attached device.
• Off. No link is detected on this port.
