• Use DHCP Server.This method passes more information to LAN devices but some IPv6 systems might not
support the DHCPv6 client function.
• Auto Config.This is the default setting.
This setting specifies how the router assigns IPv6 addresses to the devices on your home network (the LAN).
8. (Optional) Select the Use This Interface ID check box and specify the interface ID to be used for the IPv6
address of the router’s LAN interface.
If you do not specify an ID here, the router generates one automatically from its MAC address.
9. Click the Apply button.
Your settings are saved.
Set Up an IPv6 DHCP Internet Connection
To set up an IPv6 Internet connection with a DHCP server:
1. Launch a web browser from a computer or WiFi device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router user name and password.
The user name is admin.The default password is password.The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Advanced Setup > IPv6.
The IPv6 page displays.
Specify Your Internet Settings
34
