NETGEAR R7500 Quick Start

1
LEDs
The LEDs on the top of the router light to indicate router activity:
Power
Internet
2.4 GHz WiFi
5 GHz WiFi
USB 3.0 port 1
USB 3.0 port 2
eSATA port
Ethernet ports 1–4
WiFi On/O button with LED
WPS button with LED
You can use the LED O/On switch on the rear panel of the router
to turn the LEDs on the top of the router on or o.
Note: The Power LED stays lit even if the LED O/On switch is in the o
position.
LED O/On switch

NETGEAR R7500 Specifications

General

WiFi Technology	802.11ac
WiFi Performance	AC2350 (600 + 1733 Mbps)
Number of Ethernet Ports	5
Antenna	4 external antennas
Beamforming+	Yes
Dynamic QoS	Yes
MU-MIMO	Yes
VPN Support	Yes
WiFi Band	Dual Band 2.4GHz and 5GHz
Ethernet Ports Speed	Gigabit (10/100/1000 Mbps)
Processor	1.4GHz dual-core processor
Memory	512 MB RAM
Security	WPA/WPA2—PSK
Dimensions	11.22 x 7.26 x 1.97 in
