Hardware Features
Front Panel
The LEDs, buttons, and USB ports are shown in the following figure.
For more information about the LEDs and buttons, see LEDs on
page 2 and Front Panel Buttons on page 3.
Rear Panel
The rear panel connections and buttons are shown in the following
figure.
LEDs
USB 3.0 port
Reset
button
Ethernet
ports 1–6
Internet
port
Power
On/Off
button
Power
connector
USB 2.0 port
LED button
WPS button WiFi button
Ethernet
aggregate
ports 1 and 2
