Wireless-G Router WGR614v9 Reference Manual
Restricting Access From Your Network 3-5
v1.1, May 2008
• If you know that the application uses either TCP or UDP, select the appropriate protocol. If
you are not sure, select Both.
Blocking Services by IP Address Range
In the Filter Services For area, you can block the specified service for a single computer, a range of
computers (having consecutive IP addresses), or all computers on your network.
Scheduling Blocking
The Wireless-G Router allows you to specify when blocking is enforced.
To schedule blocking:
1. Select Schedule under Content Filtering in the main menu. The Schedule screen displays.
2. Configure the schedule for blocking keywords and services.
a. Days to Block. Select days on which you want to apply blocking by selecting the
appropriate check boxes. Select Every Day to select the check boxes for all days. Click
Apply.
Figure 3-4
