NETGEAR WN3100RP Installation Guide

4
Install the Extender
Place the extender, apply power, and connect it to your WiFi network.
Place the Extender and Power It On
1. Place the extender halfway between your router and the location
that has poor WiFi coverage.
If it is not possible to place the extender at the halfway point,
move the extender closer to the location with poor coverage, but
still within the wireless range of the router.
2. Turn the
On/Off
switch
On/Off switch on the side
of the extender to the On position.
3. Plug the extender into a power
outlet and wait 1 minute until the
extender starts.
The Power LED lights green.

NETGEAR WN3100RP Specifications

General

Type	Network transmitter
Maximum transfer distance	- m
Windows operating systems supported	Yes
Product color	White
Bandwidth	2.4 GHz
Cabling technology	10/100Base-T(X)
Security algorithms	WEP, WPA2-PSK, WPS
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	32.5 mm
Width	55 mm
Height	114 mm
Weight	175 g
