Getting to Know Your Wireless Router 5
Back Panel
The rear panel of the WNDR3700 router contains the items in the list that follows the figure.
The back of the N600 wireless gigabit router includes:
1. A Power On/Off button.
2. An AC power adapter outlet.
3. Four local (LAN) 10/100/1000 Mbps Ethernet ports for connecting the router to local
computers.
4. An Internet (WAN) 10/100/1000 Mbps Ethernet port for connecting the router to a cable or
DSL modem.
5. A USB 2.0 port (backward compatible to USB 1.0/1.1) for attaching a USB storage device.
For more information on modes, see “Configuring Your Wireless Settings and
Security Options” on page 20, and the online Reference Manual, available on the
Resource CD.
Figure 3
1
2
3
4
5
