NETGEAR WNR2000 User Manual

2 Getting to Know Your Wireless Router
To prepare your router for installation:
1.
Carefully peel off the protective film covering both sides of your router (see Figure 1).
2. Set up your wireless router by inserting the tabs of the stand (supplied with your router) into
the slots on the bottom of your router as shown in Figure 2. Then, remove the protective film
covering the status light panel of the router.
3. Place your router in a suitable area for installation (near an AC power outlet and accessible to
the Ethernet cables for your wired computers).
Figure 1
Figure 2
To ensure proper heat dissipation and for router stability, it is important that you
connect the stand and place your router in an upright position.

NETGEAR WNR2000 Specifications

General

Rack mounting	No
xDSL connection	Yes
Dimensions (WxDxH)	177.5 x 130 x 35 mm
Maximum data transfer rate	0 Gbit/s
WLAN data transfer rates supported	300 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Product color	Black
Wi-Fi standards	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Web-based management	-
Security algorithms	WPA, WPA2-PSK

Weight and Dimensions

Depth	132 mm
Width	48 mm
Height	108.7 mm
Weight	163 g
