NETGEAR WNR2000 User Manual

4 Getting to Know Your Wireless Router
You can use the status lights to verify various conditions. Table 1 describes each light.
Table 1. Status Light Descriptions
Label LED Activity Description
1. Power
Solid Amber
Solid Green
Fast blink–Green
Slow blink–Green
Off
The router is performing the power-on self-test diagnostic.
The power is on and the router is ready.
A software update is in progress.
There is a problem with the wireless router software.
Power is not being supplied to the router
2. Internet
Solid Amber
Solid Green
Blinking Green
Off
No IP address acquired.
The wireless router has acquired an Internet address.
Data is being communicated with the Internet.
No Ethernet cable is connected to the modem.
3. Wireless
Solid Blue
Blinking Blue
Off
The wireless interface is enabled.
Data is being communicated over the wireless network.
The wireless interface is turned off.
4. LAN
(Ports 1–4)
Solid Green
Blinking Green
Solid Amber
Blinking Amber
Off
The local port is connected to a 100 Mbps device.
Data is being transmitted at 100 Mbps.
The local port is connected to a 10 Mbps device.
Data is being transmitted at 10 Mbps.
No link is detected on this port.
5. Push 'N'
Connect
Solid Green
Blinking Green
Off
Indicates a (WPS) connection to a WPS-capable device.
WPA-capable device can associate with the router within 2 minutes.
No WPS connection exists.

NETGEAR WNR2000 Specifications

General

Rack mounting	No
xDSL connection	Yes
Dimensions (WxDxH)	177.5 x 130 x 35 mm
Maximum data transfer rate	0 Gbit/s
WLAN data transfer rates supported	300 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Product color	Black
Wi-Fi standards	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Web-based management	-
Security algorithms	WPA, WPA2-PSK

Weight and Dimensions

Depth	132 mm
Width	48 mm
Height	108.7 mm
Weight	163 g
