16
Ethernet
Ports
(Ports 1 – 4)
• Solid Green. The local port is connected to a 100 Mbps
device.
• Solid Amber. The local port is connected to a 10 Mbps
device.
• Off. No link is detected on this port.
Push ‘N’
Connect
• Solid Green. Indicates that wireless security (WEP, WPA-PSK,
or WPA-PSK) is on.
• Off. No WPS connection exists.
Item Description
