8
netis Wireless High Power Ceiling/Wall mounted AP Router Quick Installation Guide
2 Wall Mout
1) Place the mounting kit on the wall and mark four holes of the bracket on the wall,and then drill
four holes on the wall. Please note that the U-shaped notch must be consistent with the actual
direction of the network.
2) Attach the mounting bracket to the wall by using the provided mounting kit.
3) Connect the Ethernet cable to the WAN/PoE port of the device
Marking four holes of the
bracket on the wall.
Blue Port
Yellow Port
Setscrew
Screw
To Next Page
