ASSEMBLY
1. Make sure you have read all safety instructions.
2. This tool comes completely assembled. There is no assembly required.
LOADING STAPLES
1. Make sure tool is powered off.
2. The TC0070-4 has a bottom load staple magazine. Turn tool upside down and squeeze pusher assem-
bly(Fig 1).
3. Pull pusher assembly out until it stops to reveal the staple magazine(Fig 2).
4. STAPLES: Load staples into magazine with the points facing up and out of the tool ( Fig 3). Never
attempt to completely remove pusher assembly as this may damage the tool and void the warranty. Close
pusher assembly until it snaps into place.
1
2
3
