Neve 1073N - Dimensions and Power Requirements; Dimensions; Power Requirements

1073N Channel Amplifier Issue 1.4
Dimensions
Stand-alone
Modules
Width
mm (inches)
Height
mm (inches)
Depth
mm (inches)
Approx. Weight
kg (lbs)
1073N Module 45 (1.8) 222 (8.75) 254 (10) 2.5 (5.5)
19” Rack Mounting U Depth
mm (inches)
Height
mm (inches)
Approx. Weight
kg (lbs)
2 Module Version 3 405 (16) 133 (5.25 12 (26.5)*
8 Module Version 5 405 (16) 222 (8.75) 34(75)*
*Fully populated rack
Power Requirements
Rack Units 3U 5U
Rated Voltage 100- 230V AC 100- 230V AC
Rated Frequency 50- 60 Hz 50- 60Hz
Rated Current 0.5A Max 0.8A Max
Primary Protection Fuse:
Operating Voltage 100- 230V AC 100- 230V AC
Fuse Rating and Type T0.5A H 250V
20mm x 5mm CERAMIC
T1A H 250V
20mm x 5mm CERAMIC
Location IEC Mains connector IEC Mains connector
Secondary Protection Fuse:
Output Voltage 24V DC
Fuse Rating and Type T 2.0A L 250V
20mm x 5mm GLASS
Location F1
Output Voltage 48V DC
Fuse Rating and Type T 250mA L 250V
20mm x 5mm GLASS
Location F2
Modules Power
1073N Module 127mA ±10mA at 24V DC. Negative Earth
- 9 -
