10 • Operation NEW FOCUS, Inc.
Figure 3:
Responsivity of
the
photodiode
used in the
Model 1801
(DC Version).
Figure 4:
Responsivity of
the
photodiode
used in the
Model 1811
(DC Version)
Figure 5:
Typical
frequency
response (top)
and noise floor
(bottom). At DC
the noise floor
is 3.3 pW/
for Model 1801
& 2.5 pW/
for Model 1811
0.6
0.4
0.2
0.0
800600 1000 1200
Wavelength, nm
Responsivity, A/W
400
800 1000 1200 1400 1600 1800
0.00
0.20
0.40
0.60
0.80
1.00
Wavelength, nm
Responsivity, A/W
Hz
Hz
Frequency, MHz
10 dB/div
0 40 80 120 160 200
