Newage Platinum - Page 64

64
Exploded View and Spare Parts
Item
No.
Eng. Part No. SKU No. for
spares oered
Description QTY
1 GL2-01.023.04A-01 - Lid Handle 1
2 GL2-01.023.06A-01 66931 Thermometer 1
3 GL2-01.019A-01-XX - Top Back Panel 1
4 GL2-01.023.05A-01 - Lid Bumper 2
5 H00362A-01 - Slotted Sholder Screw - Dia10x16, M8x1.25 2
6 GL2-01.018.02A-01 - Burner Ignition Cover 1
7 GL2-01.018.03A-01 66925 Rotisserie Ignition Assy 1
8 GL2-01.018.05A-01 66924 Rotisserie Burner 1
9 GL2-01.001.05A-01-XX - Fire Box Heat Deector Assy 1
10 GL2-01.010.01A-01 - Outer Back Panel 1
11 GL2-01.001.03.04A-01 - Power Plug Cable Gormmet 1
12 GL2-01.018.04A-01 65931 Halogen Light Assy 2
13 GL2-01.010.03A-01 65963 Transformer 1
14 GL2-01.010.04A-01 - Transformer Cover 1
15 GL2-01.017.02A-01
65927
Rotisserie Rod Rest Assy RH 1
16 GL2-01.016.02A-01 Rotisserie Rod Rest Assy LH 1
17 GL2-01.004.01A-01 - Outer Side Panel RH 1
18 GL2-01.006.01.03A-01 65921 Rotisserie Burner Valve 1
19 GL2-01.017.03A-01 66933 Top Rack Support RH 1
20 - 65922 Propane Gas Orice 5
21 GL2-01.006.01.02A-01 65920 Burner Valve 3
22 GL2-01.003.01A-01 - Outer Side Panel LH 1
23 GL2-01.016.03A-01 66932 Top Rack Support LH 1
24 GL2-01.009A-01-XX - Control Panel Assy 1
25 H00361A-01 65924 LED Switch 2
26 GL2-01.021A-01-XX
65956
Main Burner Bazel 5
27 GL2-01.022A-01-XX Burner Knob 5
28 GL2-01.013A-01-XX 65940 Grease Tray Assy 1
29 GL2-01.007A-01-XX 66922 Burner Assy 3
30 GL2-01.008A-01-XX 65958 Sear Burner Assy 1
31 GL2-01.011A-01-XX 66930 Briquette Tray Assy 3
32 GL2-01.011.03A-01 66929 Briquette 54
33 GL2-01.012A-01-XX 65954 Cook Grid 1
34 GL2-01.026A-01-XX 65939 Rotisserie Kit Assy 1
35 GL2-01.024A-01-XX 65930 Rotisserie Motor Support Bracket Assy 1
36 GL2-01.025A-01-XX 65929 Rotisserie Motor With Support Plate 1
37 GL2-01.020A-01-XX 66928 Warm Rack 1
38 -
-
QCC1 Type
Regulator and hose
1
39 GL2-01.002.02A-01-XX 65967 LED 5
40 GL2-06.005A-01-XX Tube Burner Assembly
1
