5
1
From the bottom of the overhead rack,
determine location for utility hook to be
installed; slide the folded end with bolt
holes of the S-hook up through the
opening in the wire grid.
WARNING:
Only install Accessory
Hooks onto initial securely
mounted Overhead Racks
Hanging S-Hook Installation
Screw in the 5/16” dia x 1/2” bolt to secure
the utility hook and tighten using a wrench.
Slide the folded end with bolt holes of
the S-hook onto the wire grid.
2
3
1
From the top of the overhead rack,
determine location for utility hook to be
installed; slide the folded end with bolt
holes of the S-hook up through the
opening in the wire grid.
Screw in the 5/16” dia x 1/2” bolt to secure
the utility hook and tighten using a wrench.
Slide the folded end with bolt holes of
the S-hook onto the wire grid.
2
3
Center Installation: Edge Installation:
