6
1
Post Mount J-Hook Installation
Slide the J-Hook down to align the rivet
nubs with the bottom of the keyhole slots.
2
Locate the desired installation location
and align the rivet nubs on the back of
the J-Hook with the large hole of the
keyhole slots on the vertical angle posts.
Note:
When installing more than one J-Hook on the same
side of the vertical angle post, start with the lowest
position and install the next hook above.
